210
Built-in Outputs Section 7-1
PLS2(887) Settings to Move from Origin to Position A
PLS2(887) Settings to Move from Position A to Position B
PLS2(887) Settings to Move from Position A to Position C
Setting details Address Data
X axis Acceleration rate: 2,000 Hz/4 ms D00010 #07D0
Deceleration rate: 2,000 Hz/4 ms D00011 #07D0
Target frequency: 100,000 Hz D00012 #86A0
D00013 #0001
Number of output pulses: 5,000 pulses D00014 #1388
D00015 #0000
Y axis Acceleration rate: 2,000 Hz/4 ms D00020 #07D0
Deceleration rate: 2,000 Hz/4 ms D00021 #07D0
Target frequency: 100,000 Hz D00022 #86A0
D00023 #0001
Number of output pulses: 5,000 pulses D00024 #1388
D00025 #0000
Setting details Address Data
X axis Acceleration rate: 2,000 Hz/4 ms D00030 #07D0
Deceleration rate: 2,000 Hz/4 ms D00031 #07D0
Target frequency: 100,000 Hz D00032 #86A0
D00033 #0001
Number of output pulses: 25,000 pulses D00034 #61A8
D00035 #0000
Y axis Acceleration rate: 2,000 Hz/4 ms D00040 #07D0
Deceleration rate: 2,000 Hz/4 ms D00041 #07D0
Target frequency: 100,000 Hz D00042 #86A0
D00043 #0001
Number of output pulses: 50,000 pulses D00044 #C350
D00045 #0000
Setting details Address Data
X axis Acceleration rate: 2,000 Hz/4 ms D00050 #07D0
Deceleration rate: 2,000 Hz/4 ms D00051 #07D0
Target frequency: 100,000 Hz D00052 #86A0
D00053 #0001
Number of output pulses: 35,000 pulses D00054 #88B8
D00055 #0000
Y axis Acceleration rate: 2,000 Hz/4 ms D00060 #07D0
Deceleration rate: 2,000 Hz/4 ms D00061 #07D0
Target frequency: 100,000 Hz D00062 #86A0
D00063 #0001
Number of output pulses: 50,000 pulses D00064 #C350
D00065 #0000
