4-29
4 Remote I/O Master Communications
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
4-4 User-set Allocations
4
4-4-2 Settings through Device Variables for CJ-series Unit (Master User-set Allocations Setup
Tabl e)
This example uses the following settings for unit number 0.
• OUT block 1 area and first word: WR (4), 50CH (50)
• IN block 1 area and first word: WR (4), 100CH (100)
• Allocation Size Setup Table area and first word: DM (3), 00100 (100)
This example shows user-set allocations for the following slaves.
Example Settings for User-set Allocations through Device Variables
for CJ-series Unit
Node address Outputs Inputs Product
0 16 pts 0 pts 16-pt Transistor Output Terminal
(DRT1-OD16)
1 8 pts 8 pts 8-pt input and 8-pt Output Environment-
resistant Terminal (DRT1-MD16C)
2 16 pts 16 pts CQM I/O Link Terminal (CQM1-DRT21)
3 0 pts 8 pts 8-pt Transistor Input Terminal (DRT1-
ID08)
4 None ---
5 160 pts 160 pts CJ-series DeviceNet Unit (CJ1W-
DRM21) (Slave Unit)
To Next Page
