z CIO n+12 (Master Status 1)
The device variable for CJ-series Unit that corresponds to all bits of a word starting with CIO n+12 is
as follows:
The device variables for CJ-series Units that correspond to bits 0 to 15 of a word starting with CIO
n+12 are as follows:
z CIO n+13 (Master Status 2)
The device variable for CJ-series Unit that corresponds to all bits of a word starting with CIO n+13 is
as follows:
The device variables for CJ-series Units that correspond to bits 0 to 15 of a word starting with CIO
n+13 are as follows:
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+12 0 to 15
*_Mstr1Sta Master Status 1 (The functions of bits 0 to
15 of CIO n+12 correspond to those of
bits 0 to 15 of this CJ-series Unit device
variable.)
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+12 0 *_Mstr1VefyErr Verification Error
1
*_Mstr1StruErr Structure Error
2
*_Mstr1IOErr Remote I/O Communications Error
3 --- Reserved by system
4
*_Mstr1SListErr Invalid Scan List Data Error
5
*_Mstr1IORefErr Master I/O Refresh Error
6, 7 --- Reserved by system
8
*_Mstr1FunSetErr Master Function Enable/Disable Failed
9
*_Mstr1AlocErr Master User-set Allocations User Setting
Failed
10
*_Mstr1FixAlocErr Master Fixed Allocation Area Setting
Failed
11
*_Mstr1SListRegErr Scan List Register/Clear Failed
12
*_Mstr1CycleTmSetErr Communications Cycle Time Setting
Failed
13, 14 --- Reserved by system
15
*_Mstr1IOCommSta I/O Data Communications Status
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+13 0 to 15 *_Mstr2Sta Master Status 2 (The functions of bits 0 to
15 of CIO n+13 correspond to those of
bits 0 to 15 of this CJ-series Unit device
variable.)
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+13 0 to 7 --- Reserved by system
8 to 15
*_MstrIOAlocSta Master I/O Allocation Status
