A-23
Appendices
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
A-1 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-1-2 Differences in Accessing from User Program
z CIO n+20 to n+23 (Normal Slave Table)
The device variable for CJ-series Unit that corresponds to all bits of 4 words from CIO n+20 to n+23
is as follows:
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+20 to
n+23
0 to 15 for each word *_NormSlavTblSta Normal Slave Table
Bits 0 to 15 in each word correspond to
the bits of this CJ-series Unit device vari-
able as follows:
• Bits 0 to 15 of CIO n+20 correspond to
bits 0 to 15 of this CJ-series Unit device
variable.
• Bits 0 to 15 of CIO n+21 correspond to
bits 16 to 31 of this CJ-series Unit
device variable.
• Bits 0 to 15 of CIO n+22 correspond to
bits 32 to 47 of this CJ-series Unit
device variable.
• Bits 0 to 15 of CIO n+23 correspond to
bits 48 to 63 of this CJ-series Unit
device variable.
