A-27
Appendices
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
A-1 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-1-2 Differences in Accessing from User Program
The device variable for CJ-series Units that correspond to bits 0 to 15 of 4 words from CIO n+20 to
n+23 are as follows:
z CIO n+24 (C200H Master Replacement Master Status 1)
The device variable for CJ-series Unit that corresponds to all bits of a word starting with CIO n+24 is
as follows:
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+23 0 *_NormSlavTblNdSta[48] Normal Slave Table Corresponding to
Node Address 48 Slave
1 *_NormSlavTblNdSta[49] Normal Slave Table Corresponding to
Node Address 49 Slave
2 *_NormSlavTblNdSta[50] Normal Slave Table Corresponding to
Node Address 50 Slave
3 *_NormSlavTblNdSta[51] Normal Slave Table Corresponding to
Node Address 51 Slave
4 *_NormSlavTblNdSta[52] Normal Slave Table Corresponding to
Node Address 52 Slave
5 *_NormSlavTblNdSta[53] Normal Slave Table Corresponding to
Node Address 53 Slave
6 *_NormSlavTblNdSta[54] Normal Slave Table Corresponding to
Node Address 54 Slave
7 *_NormSlavTblNdSta[55] Normal Slave Table Corresponding to
Node Address 55 Slave
8 *_NormSlavTblNdSta[56] Normal Slave Table Corresponding to
Node Address 56 Slave
9 *_NormSlavTblNdSta[57] Normal Slave Table Corresponding to
Node Address 57 Slave
10 *_NormSlavTblNdSta[58] Normal Slave Table Corresponding to
Node Address 58 Slave
11 *_NormSlavTblNdSta[59] Normal Slave Table Corresponding to
Node Address 59 Slave
12 *_NormSlavTblNdSta[60] Normal Slave Table Corresponding to
Node Address 60 Slave
13 *_NormSlavTblNdSta[61] Normal Slave Table Corresponding to
Node Address 61 Slave
14 *_NormSlavTblNdSta[62] Normal Slave Table Corresponding to
Node Address 62 Slave
15 *_NormSlavTblNdSta[63] Normal Slave Table Corresponding to
Node Address 63 Slave
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
CIO n+24 0 to 15 *_CMstrSta C200H Master Replacement Master Sta-
tus 1 (The functions of bits 0 to 15 of CIO
n+24 correspond to those of bits 0 to 15
of this CJ-series Unit device variable.)
