A-29
Appendices
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
A-1 Differences in Available Functions Depending on the CPU Unit (NJ or CJ Series)
App
A-1-2 Differences in Accessing from User Program
z D m+8 to m+14 (Slave User-set Allocations Setup Table)
z D m+15 to m+18 (Communication Cycle Time Reference Table)
z D m+19 to m+30 (Master User-set Allocations Reference Table)
z D m+31 to m+42 (Slave User-set Allocations Reference Table)
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
D m+8 0 to 7 *_SlavAlocTblCfg[0] Slave OUT 1 Area
D m+9 0 to 15 *_SlavAlocTblCfg[1] First word in Slave OUT 1 Area
D m+10 0 to 7 *_SlavAlocTblCfg[2] OUT 1 Area Size
D m+11 0 to 15 *_SlavAlocTblCfg[3] Slave IN 1 Area
D m+12 0 to 7 *_SlavAlocTblCfg[4] First word in Slave IN 1 Area
D m+13 0 to 15 *_SlavAlocTblCfg[5] IN 1 Area Size
D m+14 0 to 15 *_SlavAlocTblCfgSta Setting Results of Slave User-set Alloca-
tions Setup
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
D m+15 0 to 15 *_CycleTmRefTblSta[0] Communications cycle time setting value
D m+16 0 to 15 *_CycleTmRefTblSta[1] Communications cycle time present value
D m+17 0 to 15 *_CycleTmRefTblSta[2] Communications cycle time maximum
value
D m+18 0 to 15 *_CycleTmRefTblSta[3] Communications cycle time minimum
value
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
D m+19 0 to 7 *_MstrAlocRefTblSta[0] OUT block 1 area
D m+20 0 to 15 *_MstrAlocRefTblSta[1] First word in OUT block 1
D m+21 0 to 15 *_MstrAlocRefTblSta[2] No. of bytes in OUT block 1
D m+22 0 to 7 *_MstrAlocRefTblSta[3] IN block 1 area
D m+23 0 to 15 *_MstrAlocRefTblSta[4] First word in IN block 1
D m+24 0 to 15 *_MstrAlocRefTblSta[5] No. of bytes in IN block 1
D m+25 0 to 7 *_MstrAlocRefTblSta[6] OUT block 2 area
D m+26 0 to 15 *_MstrAlocRefTblSta[7] First word in OUT block 2
D m+27 0 to 15 *_MstrAlocRefTblSta[8] No. of bytes in OUT block 2
D m+28 0 to 7 *_MstrAlocRefTblSta[9] IN block 2 area
D m+29 0 to 15 *_MstrAlocRefTblSta[10] First word in IN block 2
D m+30 0 to 15 *_MstrAlocRefTblSta[11] No. of bytes in IN block 2
CJ-series I/O memory address NJ-series device variables for CJ-series Unit
Word address Bit Variable name CJ-series function name
D m+31 0 to 7 *_SlavAlocRefTblSta[0] Slave OUT 1 area
D m+32 0 to 15 *_SlavAlocRefTblSta[1] First word in Slave OUT 1 area
D m+33 0 to 15 *_SlavAlocRefTblSta[2] Slave OUT 1 area size
D m+34 0 to 7 *_SlavAlocRefTblSta[3] Slave IN 1 area
D m+35 0 to 15 *_SlavAlocRefTblSta[4] First word in Slave IN 1 area
