1 Features and System Configuration
CJ-series DeviceNet Units Operation Manual for NJ-series CPU Unit(W497)
1-2 Specifications
1
1-2-1 DeviceNet Unit
Remote I/O
master
Max. No. of Slaves con-
nected per DeviceNet Unit
Fixed allocations 63 nodes
User-set
allocations
By CX-
Integrator
By device
variable for
CJ-series
Unit
Max. No. of I/O points per
DeviceNet Unit
Fixed allocations 2,048 pts (64 input words, 64 output words)
User-set
allocations
By CX-
Integrator
16,000 pts (500 input words x 1 block, 500 output words x
1 block)
By device
variable for
CJ-series
Unit
32,000 pts (500 input words x 2 blocks, 500 output words x
2 blocks)
Max. No. of I/O per Slave con-
trollable by a DeviceNet Unit
Fixed allocations 2,048 pts (64 input words, 64 output words)
User-set
allocations
By CX-
Integrator
3,200 pts (100 input words, 100 output words)
By device
variable for
CJ-series
Unit
3,200 pts (100 input words, 100 output words)
Item Specifications
