Omron CJ2 Series - Page 34

7. EtherNet/IP Connection Procedure
31
7.4.2. Transferring the Tag Data Link Parameters
Transfer the tag data link parameters to the Controller.
1
Select Download from the
Network Menu.
The dialog box on the right is
displayed. Confirm that there is
no problem and click the Yes
Button.
2
Tag data link parameters are
downloaded from the Network
Configurator to the Controller.
3
The dialog box on the right is
displayed. Check the contents
and click the OK Button.
