8. Initialization Method
39
(2)Deleting tag information
In the Tag Sets Tab Page of the Edit Parameters Dialog Box, click the Delete all of unused
Tag Sets Button.
If a confirmation dialog box is displayed when deleting, click the Yes Button.
(3)Download
Right-click the Controller and select Parameter - Download from the menu that is
displayed.
No registered
tags

Omron CJ2 Series Specifications

General

CPU Units	CJ2H, CJ2M
Data Memory Capacity	32K words (CJ2M), 128K words (CJ2H)
EtherNet/IP	Yes (some models)
I/O Capacity	Up to 2, 560 I/O points
Communication Ports	Ethernet, RS-232C
Expansion Units	Up to 40 expansion units
Programming Languages	Ladder diagram, Structured text, Function block diagram
Instruction Execution Speed	0.04 μs (basic instructions)
Serial Ports	1 (RS-232C)
Expansion Slots	Up to 10 (CJ2H)
Operating Temperature	0 to 55°C
Storage Temperature	-25°C to 75°C
Power Supply Voltage	100 to 240 VAC, 24 VDC
