Omron CJ2 Series User Manual

10. Appendix 2 Setting the Tag Data Links Using the Software
64
5
The Edit Tags Dialog Box is
displayed. Select the In -
Consume Tab and click the
New Button.
6
The Edit Tag Dialog Box is
displayed.
Set the following values and
click the Regist Button.
Name: D10100
Size: 20 bytes

Omron CJ2 Series Specifications

General

CPU Units	CJ2H, CJ2M
Data Memory Capacity	32K words (CJ2M), 128K words (CJ2H)
EtherNet/IP	Yes (some models)
I/O Capacity	Up to 2, 560 I/O points
Communication Ports	Ethernet, RS-232C
Expansion Units	Up to 40 expansion units
Programming Languages	Ladder diagram, Structured text, Function block diagram
Instruction Execution Speed	0.04 μs (basic instructions)
Serial Ports	1 (RS-232C)
Expansion Slots	Up to 10 (CJ2H)
Operating Temperature	0 to 55°C
Storage Temperature	-25°C to 75°C
Power Supply Voltage	100 to 240 VAC, 24 VDC
