Omron CJ2 Series User Manual

10. Appendix 2 Setting the Tag Data Links Using the Software
75
18
Enter EIP002_OUT in the Name
Field.
Click the Regist Button.
19
The Edit Tag Set Dialog Box is
displayed. Click the Close
Button.
20
The Edit Tags Dialog Box is
displayed again.
EIP002_OUT and 20Byte are
displayed.
Select the Connections Tab.

Omron CJ2 Series Specifications

General

CPU Units	CJ2H, CJ2M
Data Memory Capacity	32K words (CJ2M), 128K words (CJ2H)
EtherNet/IP	Yes (some models)
I/O Capacity	Up to 2, 560 I/O points
Communication Ports	Ethernet, RS-232C
Expansion Units	Up to 40 expansion units
Programming Languages	Ladder diagram, Structured text, Function block diagram
Instruction Execution Speed	0.04 μs (basic instructions)
Serial Ports	1 (RS-232C)
Expansion Slots	Up to 10 (CJ2H)
Operating Temperature	0 to 55°C
Storage Temperature	-25°C to 75°C
Power Supply Voltage	100 to 240 VAC, 24 VDC
