10. Appendix 2 Setting the Tag Data Links Using the Software
77
4
Confirm that the settings are
correct and click the Regist
Button.
5
The Edit Connection Dialog Box
is displayed again. Click the
Close Button.
6
The Edit Device Parameters
Dialog Box is displayed again.
Click the OK Button.
7
When the connection is
completely allocated, the
registration destination node
address is displayed under the
device icon of the destination
device on the Network
Configuration Pane.
8
Right-click the node 2 device
and select Parameter - Edit.
