Omron CPM1A User Manual

13
Unit Max. number
of Units
Inputs Outputs Model
20 I/O points 3 Units max.
(S )
24 VDC Relays CPM1A-20EDR1
p
12 inputs
(See note.)
24 VDC Sinking transistors CPM1A-20EDT
12
inputs
8 outputs
24 VDC Sourcing transistors CPM1A-20EDT1
8 inputs 24 VDC --- CPM1A-8ED
8 outputs
--- Relays CPM1A-8ER
p
--- Sinking Transistors CPM1A-8ET
--- Sourcing Transistors CPM1A-8ET1
Expansion Units
Temperature Sensor Unit
CompoBus/S I/O
Link Unit
CPM1A-MAD01
Analog I/O Unit
CPM1A-MAD11
Analog I/O Unit
DeviceNet I/O
Link Unit
Unit Max. number
of Units
Inputs Outputs Model
Analog I/O Unit
2 analog inputs (2 words)
1 analog output (1 word)
3 Units max.
(See note.)
2 analog inputs 1 analog output CPM1A-MAD01
CPM1A-MAD11
Temperature
Sensor Unit
Thermocouple
inputs
3 Units max.
(See note.)
2 inputs (K, J)
---
CPM1A-TS001
Se so U
pu s
1 Unit max. 4 inputs (K, J) CPM1A-TS002
Platinum
resistance
thermometer
3 Units max.
(See note.)
2 inputs (Pt100, JPt100) CPM1A-TS101
t
h
ermometer
inputs
1 Unit max. 4 inputs (Pt100, JPt100) CPM1A-TS102
CompoBus/S I/O Link Unit
8 inputs and 8 outputs
3 Units max.
(See note.)
8 bits
(Inputs from the Master.)
8 bits
(Outputs to the Master.)
CPM1A-SRT21
DeviceNet I/O Link Unit
32 inputs and 32 outputs
3 Units max.
(See note.)
32 bits
(Inputs from the Master.)
32 bits
(Outputs to the Master.)
CPM1A-DRT21
Note Only one CPM1A-TS002/TS102 Temperature Sensor Unit can be connected to
the CPU Unit. If a CPM1A-TS002/102 is connected to the CPU Unit, only one
additional Expansion Unit (other than a CPM1A-TS002/102) or one Expansion
I/O Unit can be connected to the CPU Unit.
System Configuration
Section 1-2
