Omron CPM1A User Manual

66
Transistor Output Wiring (Sourcing Outputs)
Wire the outputs to the CPM1A’s CPU Unit and Expansion I/O Unit as shown in
the following diagrams.
• Always use solid wire or attach crimp connectors if a stranded wire is used.
• Don’t exceed the output capacity or the maximum common current. Refer to
2-1-3 I/O Specifications for details.
Item Specification
Output capacity 300 mA (24 VDC)
Max. common capacity 0.9 A/common
Common Common Common Common
Common
Common Common
Common Common Common
CPM1A-10CDT1-(-V1)
CPM1A-20CDT1-(-V1)/CPM1A-20EDT1
CPM1A-30CDT1-(-V1)
CPM1A-40CDT1-(-V1)
Output Configurations
24 VDC
+10%
/
–15%
24 VDC
+10%
/
–15%
24 VDC
+10%
/
–15%
24 VDC
+10%
/
–15%
00 01 02
COM COM COM 03
10 CH
00 01 02
COM COM COM 03
10 CH
04 05 07
COM 06
00 01 02
COM COM COM 03
10 CH
04 05 07
COM06
00
11 CH
02
01
03COM
00 01 02
COM COM COM 03
10 CH
04 05 07
COM06
00
11 CH
02
01
03COM
04 05 07
06COM
Load Load Load Load
Load Load Load Load Load Load Load Load
Load Load Load Load Load
Load Load
Load Load Load Load Load
Load Load Load Load Load
Load
Load
Load Load
Load
Load Load Load Load Load
Load
Wiring and Connections
Section 3-4

Omron CPM1A Specifications

General

Model	CPM1A
Type	Compact PLC
Communication Ports	RS-232C (optional)
Instruction Set	Basic and advanced instructions
Operating Temperature	0 to 55°C
Storage Temperature	-20 to 75°C
Humidity	10% to 90% RH (non-condensing)
Power Supply	24 VDC or 100-240 VAC
Expansion	Expansion I/O units available
Timers	128
Counters	256 counters
I/O Points	10, 20, 30, or 40 points (depending on model)
