10-4SectionError Log Error Codes
173
Error
code
EE-
PROM
CorrectionDetailed error codeMeaningError
code
EE-
PROM
Correction
2nd byte1st byte
Meaning
0103 Resend count exceeded (send
failed)
Commands
Bit 15: OFF
Check transceiver at remote
node.
---
0105 Node address setting error (send
failed)
Bits 08 to 14: SNA
Bits 00 to 07: SA1
Set the IP address correctly. ---
0107 Remote node not in network
(send failed)
Responses
Bit 15: ON
Check the connection to the
remote node.
---
0108 No Unit with specified unit
address (send failed)
Bits 08 to 14: DNA
Bits 00 to 07: DA1
Check the unit address at the
remote node.
---
010B CPU Unit error (send failed) Troubleshoot the error in the
CPU Unit using the PC operation
manual.
---
010D Destination address not in routing
tables (send failed)
Set the destination address in the
routing tables.
---
010E No routing table entry (send
failed)
Set the local node, remote node,
and relay nodes in the routing
tables.
---
010F Routing table error (send failed) Create the routing tables
correctly.
---
0110 Too many relay points (send
failed)
Reconstruct the network or
correct the routing tables so that
commands are sent to within a
3-level network range.
---
0111 Command too long (send failed) Check the command format and
set the correct command data.
---
0112 Header error (send failed) Check the command format and
set the correct command data.
---
0117 Internal buffers full; packet
discarded
Change the network so that traffic
is not concentrated.
---
0118 Illegal packet discarded Check for nodes sending illegal
packets.
---
0119 Local node busy (send failed) Change the network so that traffic
is not concentrated.
---
0120 Unexpected routing error Check the routing tables. ---
0121 No setting in IP address table;
packet discarded
Set the remote node in the IP
address table.
---
0122 Service not supported in current
mode; packet discarded
Select the IP address table or
both methods for the address
conversion method.
---
0123 Internal send buffer full; packet
discarded
Change the network so that traffic
is not concentrated.
---
0124 Maximum frame size exceeded;
routing failed
Reduce the size of events. ---
021A Logic error in setting table 00 01: Data link
table
02: Network
parameters
03: Routing
tables
04: Setup
05: CPU Bus
Unit Words
(CIO/DM)
Recreate the data specified by
the 2nd byte of the detailed error
code.
Saved
