Omron CS1W-ETN01 User Manual

Appendix FCPU Bus Unit Allocations in the CPU Unit
244
Socket Services Parameter Area 1 to 8 (Ethernet Unit to CPU Unit)
Offset Socket
No. 1
Socket
No. 8
UDP/TCP socket number (1 to 8)
Local UDP/TCP port number (0000 to FFFF Hex)
Remote IP address (00000000 to FFFFFFFF Hex)
Number of send/receive bytes (0000 to 07C0 Hex (1984))
Send/receive data address
(Same as FINS variable area designation method.)
Timeout value (0000 to FFFF Hex)
Response code
Remote UDP/TCP port number (0000 to FFFF Hex)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
...
+0
+1
+2
+4
+5
+6
+8
+9
m+18 m+88
...
m+19 m+89
m+20
m+21
m+90
m+91
m+22
m+92
...
m+23
m+93
m+24 m+94
m+25 m+95
m+26 m+96
m+27 m+97
...
IP Address Display Area
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
m+98
m+99
SW1 SW2 SW3 SW4
SW5 SW6 SW7 SW8
The set values of the Local IP Address Switches (rotary switches 1 to 8) on the
back of the Ethernet Unit are read and stored here when the power is turned ON.
If an incorrect address is set, 0000 (Hex) will be stored here and the ERC indica-
tor will flash. (Refer to 3-4-3 Setting the Local IP Address.)
