Instance Specifications
Section 2-3
Function Block Holding Area (H512 to H1535)
The default allocation of Function Block Holding Area words set as retained
and non-retained words is H512 to H1535. These words are different to the
standard Holding Area used for programs (H000 to H511), and are used only
for the function block instance area (internally allocated variable area).
• These words cannot be specified in AT settings for internal variables.
• These words cannot be specified as instruction operands.
• These words are displayed in red if they are input when a function
block is not being created.
• Although the words can be input when creating a function block, an
error will occur when the program is checked.
• If this area is specified as non-retained, turn the power ON/OFF or clear
the area without retaining the values when starting operation.
Note To prevent overlapping of instance area addresses with addresses used in the
program, set H512 to H1535 (Function Block Holding Area words) for the non-
retained area and retained area. If there are not sufficient words, use words in
areas not used by the user program.
FQM1 Flexible Motion controller
Non-retained Areas
Note (1) Except when the data type is set to TIMER or COUNTER.
(2) Bit data can be accessed even if the DM Area is specified for the non-re-
tained area.
Retained Area
None
Timer Area
Counter Area
FB Instance
Area
Default value Applicable memory
areas
Start address End address Size
Non Retain 5000 5999 1000 CIO, WR, DM
Retain None
Timers T206 T255 50 TIM
Counters C206 C255 50 CNT
Item Contents
Allocated variables Variables for which the retain property for power OFF and
operation start is set as retained. (See note 1.)
Applicable areas I/O (CIO), W (Work Area), and D (DM Area) (See note 2.)
Setting unit Set in words
Allocated words
(default)
CIO 5000 to CIO 5999
Item Contents
Allocated variables Variables with TIMER set as the data type.
Applicable areas T (Timer Area) Timer Flag (1 bit) or timer PVs (16 bits)
Allocated words
(default)
T206 to T255 Timer Flag (1 bit) or timer PVs (16 bits)
Item Contents
Allocated variables Variables with COUNTER set as the data type.
To Next Page
