Omron E5AC-T User Manual

6 - 29
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-5 Adjustment Level
6
This parameter measures the heater current from the CT input used for detecting heater burnout.
fsp
Fixed SP
• This parameter sets the SP used in Fixed SP Mode.
z Related Parameters
SP Mode (Adjustment Level): Page 6-28
ct1
Heater Current 1 Value Monitor
HB and HS alarms must be supported.
The HB ON/OFF parameter must be set to ON.
This parameter measures and displays the heater current value.
• Heater burnout is not detected if the ON time for the control output for heating is 100 ms
or less (30 ms or less if the control period is 0.1 or 0.2 s).
• ffff is displayed when 55.0 A is exceeded.
• If an alarm is output for the Heater Burnout Detection 1 parameter, the No. 1 display will
flash the Heater Current 1 Value Monitor parameter.
z Related Parameters
Heater Burnout Detection 1 (Adjustment Level): Page 6-30
Heater Burnout Detection 2 (Adjustment Level): Page 6-31
HB ON/OFF (Advanced Function Setting Level): Page 6-84
Error Displays ct1: Page A-13
Function
Setting
Setting range Unit Default
SP Lower Limit to SP Upper Limit EU 0
See
See
Function
Monitor
Monitor range Unit
0.0 to 55.0 A
See
See
