Omron E5AC-T User Manual

6 Parameters
6 - 42
E5@C-T Digital Temperature Controllers User’s Manual (H185)
oc-h
Open/Close Hysteresis A Position-proportional Model must be used.
• The Open/Close Hysteresis parameter is used to shift the ON and OFF points for the
open output and close output to prevent output chattering.
z Related Parameters
Position Proportional Dead Band (Adjustment Level): Page 6-41
sqrp
Extraction of Square Root Low-cut
Point
The input type must be an analog input, and the
Extraction of Square Root Enable parameter must
be set to ON.
• This parameter sets the extraction of square root low-cut point used for the inputs. The
data after extracting the square root is shown below.
• The low-cut point is used for extracting the square root for flowrate sensors.
z Related Parameters
Extraction of Square Root Enable (Initial Setting Level): Page 6-78
Function
Setting
Setting range Unit Default
0.1 to 20.0 % 0.8
See
See
Function
0
Argument 1 (input data)
Operation result
100% FS
100% FS
Extraction of square
root low-cut point
Setting
Setting range Unit Default
0.0 to 100.0 % 0.0
See
See
