Omron E5AC-T User Manual

6 - 73
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-9 Initial Setting Level
6
tr-h
Transfer Output Upper Limit
There must be a transfer output.
The transfer output type must not be set to OFF.
tr-l
Transfer Output Lower Limit
• This parameter sets the upper and lower limit values of transfer outputs.
*1 This function can be set for a Position-proportional Model, but the setting will be disabled.
*2 This function can be set for standard control or for a Position-proportional Model, but the setting
will be disabled.
*3 This setting is displayed only for a Position-proportional Model.
z Related Parameter
Transfer Output Type (Initial Setting Level): Page 6-72
Function
Setting
Transfer
output type
Setting range
Default
Unit
Transfer output
lower limit
Transfer output
upper limit
Present SP SP lower limit to SP upper limit SP lower limit SP upper limit EU
PV Temperature
input
Input setting range
lower limit to input
setting range upper
limit
Input setting
range lower limit
Input setting
range upper
limit
Analog input Analog scaling
lower limit to analog
scaling upper limit
Scaling lower
limit
Scaling upper
limit
MV
(heating)
*1
Standard −5.0 to 105.0 0.0 100.0 %
Heating/
cooling
0.0 to 105.0
MV
(cooling)
*2
Valve
opening
*3
Position-
proportional
control
−10.0 to 110.0
See
See
