Setting the No. 3 Display Section 3-11
Operating Procedure This procedure displays PV/SP/MV and PV/SP/Bank No. on the Process
Value/Set Point display. The PV/SP Display Screen Selection parameter is set
to 2.
Operation Level
1. Press the O Key for at least three seconds to move from the operation
level to the initial setting level.
Initial Setting Level
2. Press the M Key to select the Move to Advanced Function Setting Level
parameter.
Initial Setting Level
3. Use the D Key to enter the password (“−169”).
It is possible to move to the advanced function setting level by either
pressing the M Key or waiting two seconds without pressing any key.
Advanced Function Setting Level
4. Press the M Key to select the PV/SP Display Screen Selection parame-
ter.
Advanced Function Setting Level
5. Use the U and D Keys to set 2.
6. Press the O Key for at least one second to move from the advanced
function setting level to the initial setting level.
Initial Setting Level
7. Press the O Key for at least one second to move from the initial setting
level to the operation level.
The MV will be displayed on the No. 3 display.
Operation Level
8. Press the M Key to confirm that the Bank No. is displayed on the No. 3
Operation Level
PV/SP
25.0
100.0
C
50.0
Input Type
in-t
5
amov
-169
Move to
Advanced
Function Setting
Level
Parameter
Initialization
init
off
spdp
4
PV/SP Display
Screen Selection
spdp
2
in-t
5
Input Type
25.0
100.0
50.0
PV/SP
C
PV/SP
25.0
100.0
b.0
C
