Performing Manual Control Section 4-13
Operating Procedure In this example, A-M (Auto/Manual) is set for the PF Setting parameter
(E5AN/EN-H only).
6. Use the U Key to set the parameter to ON. (The default is ON.)
Initial Setting Level
7. Press the O Key for at least one second to move from the advanced
function setting level to the initial setting level.
8. Press the O Key for at least one second to move from the initial setting
level to the operation level.
Operation Level
9. Select the Auto/Manual Switch parameter by pressing the M Key.
Manual Control Level
10. Press the O Key for at least three seconds to move from the operation
level to the manual control level.
11. Press the U or D Key to set the manual MV. (In this example, the MV is
set to 500%.)
Note The manual MV setting must be saved (see page 14), but values
changed with Key operations are reflected in the control output
immediately.
Operation Level
12. Press the O Key for at least one second to move from the manual control
level to the operation level.
amad
on
in-t
5
Input Type
a-m
Auto/Manual
Switch
C
25.0
0.0
PV/M
V
C
25.0
50.0
C
25.0
100.0
al
m
▲
▲
Operation Level
Initial Setting Level
1. Press the O Key for at least three seconds to move from the operation
level to the initial setting level.
2. Select the PID ON/OFF parameter by pressing the U Key. (The default
is PID.)
Initial Setting Level
3. Select the Move to Advanced Function Setting Level parameter by press-
ing the M Key. (For details on moving between levels, refer to 4-8 Moving
to the Advanced Function Setting Level.)
C
25.0
100.0
al
m
▲
▲
in-t
5
Input Type
cntl
pid
amov
0
Move to Ad-
vanced Function
Setting Level
