151
Counting Control Output ON/OFF Operations Section 4-21
Control Output ON/
OFF Counter Monitor
Function
This function is not displayed when the Control Output 1 ON/OFF Alarm Set
Value and the Control Output 2 ON/OFF Alarm Set Value parameter are set to
0, or when the control outputs are set for linear outputs.
Display When ON/OFF Count Alarm Occurs
When an ON/OFF count alarm occurs, the PV display in the No. 1 display
shown below alternates with the ralm display on the No. 2 display.
•PV
• PV/SP (Including the items displayed by setting the “PV/SP” Display
Screen Selection parameter.)
• PV/Manual MV (Valve Opening), PV/SP/Manual MV (Valve Opening)
• PV/SP displayed for the monitor/setting items
Control Output ON/
OFF Count Alarm
Function
If the ON/OFF counter exceeds the control output ON/OFF count alarm set
value, an ON/OFF count alarm will occur. The alarm status can be assigned
to a control output or an auxiliary output, or it can be displayed at the Control-
ler. The ON/OFF count alarm set value function is disabled by setting the ON/
OFF count alarm set value to 0.
ON/OFF Counter Reset Function
The ON/OFF counter can be reset for a specific control output.
Note After the counter has been reset, the control output ON/OFF count monitor
value will be automatically returned to 0.
If an error occurs in the control output ON/OFF counter data, the ON/OFF
count monitor value will be set to 9999 and an ON/OFF count alarm will occur.
The alarm can be cleared by resetting the ON/OFF counter.
Parameter name Setting range Unit Default
Control Output 1 ON/OFF Count Monitor 0 to 9999 100 times 0
Control Output 2 ON/OFF Count Monitor 0 to 9999 100 times 0
PV/SP
25.0
100.0
25.0
ralm 100.0
CC
Normal
ON/OFF Count Alarm
Alternating
display
Parameter name Setting range Unit Default
Control Output 1 ON/OFF Alarm Set
Value
0 to 9999 100 times 0
Control Output 2 ON/OFF Alarm Set
Value
0 to 9999 100 times 0
Parameter name Setting range Unit Default
ON/OFF Counter Reset 0: Disable the counter reset
function.
1: Reset the control output 1
ON/OFF counter.
2: Reset the control output 2
ON/OFF counter.
--- 0
