PID Setting Level Section 5-6
• MV Upper Limit
The setting range depends on whether standard, position-proportional
(closed) control, or heating/cooling control is used. In addition, the cooling
MV during heating/cooling control is expressed as a negative value.
• MV Lower Limit
The setting range depends on whether standard, position-proportional
(closed) control, or heating/cooling control is used. In addition, the cooling
MV during heating/cooling control is expressed as a negative value.
■ Related Parameters
PID ON/OFF: Page 228
ST (initial setting level): Page 228
These parameters set the upper limit for each PID set when PID sets are
selected automatically.
• These parameters are used to set the automatic selection range upper
limits for PID sets 1 to 8.
• The sensor setting range for PID set 8 is 32,400 EU for temperature
inputs and 105.0% for analog inputs. This parameter does not need to be
set.
• These values apply to the PV (process value), DV (deviation), or SP (set
point) set in the PID Set Automatic Selection Data parameter. The default
setting is PV.
■ Related Parameters
PID set automatic selection data (advanced function setting level): Page 269
Control method Setting range Unit Default
Standard MV lower limit + 0.1 to 105.0 % 105.0
Heating/cooling 0.0 to 105.0
Position-propor-
tional (closed)
MV lower limit + 0.1 to 105.0
Control method Setting range Unit Default
Standard −5.0 to MV lower limit - 0.1 % −5.0
Heating/cooling −105.0 to 0.0 −105.0
Position-propor-
tional (closed)
−5.0 to MV upper limit - 0.1 −5.0
Settin
g
See
See
*.aut
PID * Automatic Selection Range Upper
Limit (*: 1 to 8)
2-PID control must be used.
Setting range Unit Default
Temperature: −19,999 to
32,400
EU 1320.0
Analog: −5.0 to 105.0 % 105.0
Function
Settin
g
See
See
