Omron E5AN-H User Manual

226
Initial Setting Level Section 5-9
• These parameters can be used when the input type is set for an analog
input.
• When an analog input is used, scaling is performed. Set the upper limit in
the Scaling Upper Limit parameter and the lower limit in the Scaling Lower
Limit parameter.
• The Decimal Point parameter specifies the decimal point position of
parameters (set point, etc.) whose unit is EU.
• Scaling Upper Limit, Scaling Lower Limit
• Decimal Point
■ Related Parameters
Input type (initial setting level): Page 224
• Set the temperature input unit to either °C or °F.
■ Related Parameters
Input type (initial setting level): Page 224
in-h Scaling Upper Limit
The input type must be set for an
analog input.
in-l Scaling Lower limit
dp Decimal Point
Parameter name Setting range Unit Default
Scaling Upper Limit Scaling lower limit + 1 to 32400 None 100
Scaling Lower Limit −19999 to scaling upper limit − 1None 0
Parameter name Setting range Default
Decimal Point 0 to 3 0
Set value Settings Example
0 0 digits past decimal point 12345
1 1 digits past decimal point 1234.5
2 2 digits past decimal point 123.45
3 3 digits past decimal point 12.345
Function
Setting
See
See
d-u Temperature Unit
The input type must be set for a tem-
perature input.
Setting range Default
c: °C, f: °F c
Function
Setting
See
See
