247
Advanced Function Setting Level Section 5-10
• This parameter sets hysteresis for heater burnout detection.
â–  Related Parameters
HB ON/OFF (advanced function setting level): Page 246
• The setting of this parameter determines when ST operates.
This parameter cannot be used when ST is set to OFF.
â–  Related Parameters
Input type: Page 224, PID ON/OFF: Page 228, ST: Page 228 (initial setting
level)
• Normally, use the default for this parameter.
• This parameter sets the 2-PID control α constant.
hbh Heater Burnout Hysteresis
The Heater Burnout parameter must
be set to ON.
The Heater Burnout Latch parameter
must be set to OFF.
Heater burnout, HS alarms, and
heater overcurrent detection must be
supported.
Alarm 1 must be assigned.
Setting range Unit Default
0.1 to 50.0 A 0.1
Function
Setting
See
See
st-b ST Stable Range
ST must be ON and temperature
input, standard control, 2-PID control
must be set.
Setting range Unit Default
0.1 to 3240.0 °C or °F15.0
Function
Setting
See
See
alfa α
ST must be OFF and 2-PID control
must be set.
Setting range Unit Default
0.00 to 1.00 None 0.65
Function
Setting
