Advanced Function Setting Level Section 5-10
Use the PV color change function to change the color of the PV display (No. 1
display).
There are three display colors, orange, red, and green, and you can select
from the following three modes and eight types.
• Constant: This mode displays orange, red, or green all the time.
• Linked to Alarm 1: This mode switches the PV display color from red to
green when alarm 1 turns ON or from green to red when alarm 1 turns
ON.
• Linked to PV stable band: This mode switches the PV display color
between red outside the PV stable band and green within PV stable band,
or between green outside the PV stable band and red within PV stable
band. Set the PV stable band in the PV Stable Band parameter in the
advanced function setting level.
• The default is red (red).
The following table shows the display functions that can be set using the PV
color change function.
colr PV Change Color
Function
Setting
Mode Setting Function PV change color Application example
Constant org Orange Constant: Orange To match the display color
with other Controller models
red Red Constant: Red To match the display color
with other Controller models
grn Green Constant: Green To match the display color
with other Controller models
Linked to
alarm 1
ALM1 ON ALM1
OFF
Application example
r-g Red to
Green
Red Green To display the PV reached
signal
g-r Green to
Red
Green Red To display error signals
PV
SP
OFF
ON
Alarm
value
ALM1 ON
