293
Calibrating the Transfer Output
Section 6-6
2. Press the M Key to switch to the Transfer Output Screen.
3. The 20 mA Calibration Screen will be displayed. Use the U and D Keys to adjust
the DMM monitor value to 20 mA, and then press the M Key. The contents of the
calibration will be temporarily registered.
4. The 4 mA Calibration Screen will be displayed. Use the U and D Keys to adjust
the DMM monitor value to 4 mA, and then press the M Key. The contents of the
calibration will be temporarily registered.
5. Press the U Key. The No. 2 display changes to yes. Release the key and wait two
seconds or press the M Key. This stores the temporarily registered calibration data
to EEPROM.
To cancel the saving of temporarily registered calibration data to EEPROM, press
the M Key (while no is displayed in the No. 2 display) without pressing the U Key.
6. The calibration mode is quit by turning the power OFF.
str
no
a20.t
52ac
a4.t
0037
str.t
no
