298
Appendix
E5AN-H/EN-H Output Unit Ratings
HB, HS, and Heater Overcurrent Alarms (for E5CN/AN/EN-H Controllers with Heater
Burnout, HS, and Heater Overcurrent Alarms)
Note (1) When the control output 1 ON time is less than 100 ms, heater burnout detection, heater overcurrent
detection, and heater current measurement are not performed.
(2) When the control output 1 OFF time is less than 100 ms, HS alarm, and leakage current measure-
ment are not performed.
Characteristics
Model Output type Output form Specifications
E53-RN Relay ON/OFF 250 VAC, 5 A (resistive load), electrical durability: 100,000 opera-
tions
E53-QN
E53-Q3
E53-Q4
Voltage (PNP)
Voltage (NPN)
Voltage (PNP)
ON/OFF
ON/OFF
ON/OFF
PNP type, 12 VDC, 40 mA (with short-circuit protection)
NPN type, 24 VDC, 20 mA (with short-circuit protection)
PNP type, 24 VDC, 40 mA (with short-circuit protection)
E53-C3N
E53-C3DN
4 to 20 mA
0 to 20 mA
Linear
Linear
4 to 20 mA DC, Load: 600 Ω max., Resolution: approx. 10,000
0 to 20 mA DC, Load: 600 Ω max., Resolution: approx. 10,000
E53-V34N
E53-V35N
0 to 5 V
0 to 10 V
Linear
Linear
0 to 10 VDC, Load: 1 kΩ max., Resolution: approx. 10,000
0 to 5 VDC, Load: 1 kΩ max., Resolution: approx. 10,000
Max. heater current 50 A AC
Input current readout accuracy ±5% FS ±1 digit max.
Heater burnout alarm setting
range
0.1 to 49.9 A (0.1 A units)
0.0 A: Heater burnout alarm output turns OFF.
50.0 A: Heater burnout alarm output turns ON.
Min. detection ON time: 100 ms (See note 1.)
HS alarm setting range 0.1 to 49.9 A (0.1 A units)
0.0 A: HS alarm output turns ON.
50.0 A: HS alarm output turns OFF.
Min. detection OFF time: 100 ms (See note 2.)
Heater overcurrent alarm setting
range
0.1 to 49.9 A (0.1 A units)
0.0 A: Heater overcurrent alarm output turns ON.
50.0 A: Heater overcurrent alarm output turns OFF.
Min. detection OFF time: 100 ms
Indication accuracy
(ambient temperature of
23°C)
Thermocouple (See note 1.):
(±0.1% of indication value or ±1°C, whichever is greater) ±1 digit max.
Platinum resistance thermometer:
(±0.1% of indication value or ±0.5°C, whichever is greater) ±1 digit max.
Analog input: ±0.1% FS ±1 digit max.
CT input: ±5% FS ±1 digit max.
Temperature variation
influence (See note 2.)
Thermocouple (R, S, B, W, PLII)
(±1% of PV or ±10°C, whichever is greater) ±1 digit max.
Other thermocouples:
(±1% of PV or ±4°C, whichever is greater) ±1 digit max.
*K thermocouple at −100°C max: ±10°C max.
Platinum resistance thermometer:
(±1% of PV or ±2°C, whichever is greater) ±1 digit max.
Analog input: ±1% FS ±1 digit max.
Voltage variation influence
(See note 2.)
Hysteresis Temperature Input 0.1 to 3240.0°C or °F
(in units of 0.1°C or °F)
Analog Input 0.01% to 99.99% FS (in units of 0.01% FS)
