Appendix
Note (1) The indication accuracy of K thermocouples in the −200 to 1,300°C range, T and N thermocouples
at a temperature of −100°C or less, and U and L thermocouples at any temperature is ±2°C ±1 digit
maximum. The indication accuracy of B thermocouples at a temperature of 400°C to 800±3°C or
less is not specified. The indication accuracy of R and S thermocouples at a temperature of 200°C
or less is ±3°C ±1 digit maximum. The indication accuracy of W thermocouples is (the larger of
±0.3% or ±3°C) ±1 digit maximum and the indication accuracy of PLII thermocouples is (the larger
of ±0.3% or ±2°C) ±1 digit maximum.
(2) Ambient temperature: −10°C to 23°C to 55°C
Voltage range: −15 to +10% of rated voltage
Proportional band (P) Temperature Input 0.1 to 3240.0°C or °F
(in units of 0.1°C or °F)
Analog Input 0.1% to 999.9% FS (in units of 0.1% FS)
Integral time (I) Standard, heating/cooling, position proportional (closed): 0.0 to 3240.0
Position proportional (floating): 0.1 to 3240.0 (in units of 0.1 s)
Derivative time (D) 0.0 to 3240.0 (in units of 0.1 s)
Control Period 0.5, 1 to 99 s (in units of 1 s)
Manual reset value 0.0% to 100.0% (in units of 0.1%)
Alarm setting range −19,999 to 32,400 (decimal point position depends on input type)
Sampling period 60 ms
Insulation resistance 20 MΩ min. (at 500 VDC)
Dielectric strength 2,300 VAC, 50/60 Hz for 1 min between terminals of different charge
Malfunction vibration
10 to 55 Hz, 20 m/s
2
for 10 min each in X, Y and Z directions
Vibration resistance
10 to 55 Hz, 20 m/s
2
for 2 hr each in X, Y, and Z directions
Malfunction shock
100 m/s
2
, 3 times each in X, Y, and Z directions
Shock resistance
300 m/s
2
, 3 times each in X, Y, and Z directions
Weight E5CN-H Approx. 150 g Adapter: approx. 10 g Terminal cover: approx. 10 g
E5AN-H Approx. 310 g Adapter: approx. 100 g Terminal cover: approx.
1.6 g per cover
E5EN-H Approx. 260 g
Degree of protec-
tion
E5CN-H
E5AN-H
E5EN-H
Front panel: IP66
Rear case: IP20
Terminals: IP00
Memory protection EEPROM (non-volatile memory) (number of writes: 1,000,000)
