Appendix
Note (1) The parameters in the current PID set will be accessed.
(2) The parameters in the current bank will be accessed.
(3) Not displayed for heating/cooling control or floating control (for models with position-proportional
control).
MV Upper Limit
(See note 1.)
ol-h Standard: MV lower limit (0.1
to 105.0
Heating/cooling: 0.0 to 105.0
105.0 %
Position proportional (closed):
MV upper limit (0.1 to 105.0)
MV Lower Limit
(See note 1.)
ol-l Standard: −5.0 to MV upper
limit −0.1
−5.0 %
Heating/cooling: −105.0 to 0.0 −105.0
Position proportional (closed):
−5.0 to MV upper limit −0.1
−5.0
MV Change Rate
Limit
orl 0.0 to 100.0
(0.0: MV Change Rate Limit
Disabled)
0.0 %/s
Position Propor-
tional Dead Band
db Position proportional (closed):
0.1 to 10.0
4.0 %
Position proportional
(floating): 0.1 to 10.0
2.0
Open/Close Hystere-
sis
oc-h 0.1 to 20.0 0.8 %
Extraction of Square
Root Low-cut Point
sgrp 0.0 to 100.0 0.0 %
Parameters Characters Setting (monitor) value Display Default Unit Set value
