Omron E5AN-H

313
Appendix
Proportional Band
(See note 1.)
p Universal input: 0.1 to 3240.0 8.0 °C or °F
(See note
1.)
Analog input: 0.1 to 999.9 10.0 %FS
Integral Time
(See note 1.)
i Standard, heating/cooling,
position proportional (closed):
0.0 to 3240.0
Position proportional
(floating): 0.1 to 3240.0
233.0 Second
Derivative Time
(See note 1.)
d 0.0 to 3240.0 40.0 Second
0.0 to 3240.0 40.0 Second
Cooling Coefficient
(See note 1.)
c-sc 0.01 to 99.99 1.00 None
Dead Band c-db Temperature input: −1999.9 to
3240.0
0.0 °C or °F
Analog input: −19.99 to 99.99 0.00 %FS
Manual Reset Value of-r 0.0 to 100.0 50.0 %
Hysteresis (Heating) hys Temperature input: 0.1 to
3240.0
1.0 °C or °F
Analog input: 0.01 to 99.99 0.10 %FS
Hysteresis (Cooling) chys Temperature input: 0.1 to
3240.0
1.0 °C or °F
Analog input: 0.01 to 99.99 0.10 %FS
Soak Time
(See note 2.)
soak 1 to 9,999 1 min or h
Wait Band
(See note 2.)
wt-b Temperature input: OFF,
0.1 to 3240.0
off, 0.1 to
3240.0
OFF °C or °F
Analog input: OFF, 0.01 to
99.99
off, 0.01 to
99.99
OFF %FS
MV at Stop mv-5 Standard: −5.0 to 105.0
Heating/cooling: −105.0 to
105.0
0.0 %
Position proportional (Float-
ing or Direct Setting of Posi-
tion Proportional MV
parameter set to OFF): CLOS,
HOLD, OPEN
clos,
hold, open
HOLD None
Position proportional (Close
and Direct Setting of Position
Proportional MV parameter
set to ON):
−5.0 to 105.0
0.0 %
MV at PV Error mv-e Standard: −5.0 to 105.0
Heating/cooling: −105.0 to
105.0
0.0 %
Position proportional (Float-
ing or Direct Setting of Posi-
tion Proportional MV
parameter set to OFF): CLOS,
HOLD, OPEN
clos,
hold, open
HOLD None
Position proportional (Close
and Direct Setting of Position
Proportional MV parameter
set to ON):
−5.0 to 105.0
0.0 %
SP Ramp Set Value
(See note 2.)
sprt OFF or 1 to 9,999 off, 1 to
9999
OFF EU/s, EU/
min, EU/h
Parameters Characters Setting (monitor) value Display Default Unit Set value
