PID Setting Level
Parameters Characters Setting (monitor) value Display Default Unit Set value
Display PID Selec-
tion
d.pid 1 to 8 (See note 1.)
PID 1 Proportional
Band
up Temperature input: 0.1 to
3240.0
8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
PID 1 Integral Time 1.i Standard/heating/cooling,
position proportional (closed):
0.0 to 3240.0
233.0 s
Position proportional (floating):
0.1 to 3240.0
PID 1 Derivative
Time
1.d 0.0 to 3240.0 40.0 s
PID 1 MV Upper
Limit
1.olh Standard: MV lower limit (0.1
to 105.0)
Heating/cooling: 0.0 to 105.0
105.0 %
Position proportional (closed):
MV lower limit (0.1 to 105.0)
PID 1 MV Lower
Limit
1.oll Standard: −5.0 to MV upper
limit −0.1
−5.0 %
Heating/cooling: −105.0 to 0.0 −105.0
Position proportional (closed):
−5.0 to MV upper limit −0.1
−5.0
PID 1 Automatic
Selection Range
Upper Limit
1.aut Temperature input: −19999 to
32400
1320.0 EU
Analog input: −5.0 to 105.0 105.0 % (See
note 2.)
PID 1 Cooling Coef-
ficient
1.csc 0.01 to 99.99 1.0 None
PID 1 LBA Detec-
tion Time
1.lbr 0 to 9999 (0: LBA function
disabled)
0s
PID 2 Proportional
Band
2.p Temperature input: 0.1 to
3240.0
8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
to
PID 2 LBA Detec-
tion Time
2.lbr 0 to 9999 (0: LBA function
disabled)
0s
PID 3 Proportional
Band
3.p Temperature input: 0.1 to
3240.0
8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
to
PID 3 LBA Detec-
tion Time
3.lbr 0 to 9999 (0: LBA function
disabled)
0s
PID 4 Proportional
Band
4.p Temperature input: 0.1 to
3240.0
8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
to
PID 4 LBA Detec-
tion Time
4.lbr 0 to 9999 (0: LBA function
disabled)
0s
PID 5 Proportional
Band
5.p Temperature input: 0.1 to
3240.0
8.0 °C or °F
Analog input: 0.1 to 999.9 10.0 %FS
to
