Appendix
Auxiliary Output 1
Open in Alarm
sb1n N-O: Close in alarm
N-C: Open in alarm
n-o, n-c N-O None
Auxiliary Output 2
Open in Alarm
sb2n N-O: Close in alarm
N-C: Open in alarm
n-o, n-c N-O None
Auxiliary Output 3
Open in Alarm
sb3n N-O: Close in alarm
N-C: Open in alarm
n-o, n-c N-O None
Heater Burnout
Latch
hbl OFF, ON off, on OFF None
Heater Burnout Hys-
teresis
hbh 0.1 to 50.0 0.1 A
ST Stable Range st-b 0.1 to 3240.0 15.0 °C or °F
α alfa 0.00 to 1.00 0.65 None
AT Calculated Gain at-g 0.1 to 10.0 0.8 None
AT Hysteresis at-h Universal input: 0.1 to 3240.0 0.8 °C or °F
Analog input: 0.01 to 9.99 0.20 %FS
Limit Cycle MV
Amplitude
lcma 5.0 to 50.0 20.0 %
Input Digital Filter inf 0.0 to 999.9 0.0 Second
Additional PV Dis-
play
pvad OFF, ON off, on OFF None
MV Display o-dp OFF, ON off, on OFF None
Automatic Display
Return Time
ret OFF or 1 to 99 off, 1 to
99
OFF Second
Alarm 1 Latch a1lt OFF, ON off, on OFF None
Alarm 2 Latch a2lt OFF, ON off, on OFF None
Alarm 3 Latch a3lt OFF, ON off, on OFF None
Move to Protect
Level Time
prlt 1 to 30 3 Second
Input Error Output sero OFF, ON off, on OFF None
Cold junction Com-
pensation Method
cjc OFF, ON off, on ON None
MB Command Logic
Switching
rlrv OFF, ON off, on OFF None
PV Change Color colr Orange, Red, Green
Red to Green: When ALM1 is
ON,
Green to Red: When ALM1 is
ON
Red to Green to Red
Within PV stable band:
Green
Outside stable band: Red
Green to Orange to Red
Within PV stable band:
Green
Outside stable band: Green,
Red
Orange to Green to Red
Within PV stable band:
Green
Outside stable band: Green,
Red
org, red,
grn
r-g
g-r
r-g.r
g-o.r
o-g.r
RED None
PV Stable Band pv-b Temperature input: 0.1 to
3240.0
5.0 °C or °F
(See note
1.)
Analog input: 0.01 to 99.99 5.00 %FS
Parameters Characters Setting (monitor) value Display Default Unit Set value
