Appendix
(6) Refer to the following table.
(6.1) Initialized when the transfer output type is changed.
Initialized if the input type, temperature unit, scaling upper/lower limit, or SP upper/
lower limit is changed when the transfer output type is SP, ramp SP, or PV.
(7) The setting of PRST (program start) will be ignored if the Program Pattern parameter is set to OFF.
(8) Can be selected only for models with the remote SP function.
(9) This setting will be ignored for heating/cooling control or for floating control (for models with position-
proportional control).
(10) Displayed only for models with communications.
(11) The parameter will be “NONE” for models with event inputs 3 and 4.
Manual Control Level
Note (1) When the Manual MV Limit Enable parameter is set to ON, the setting range will be the MV lower
limit to the MV upper limit.
(2) The valve opening will be monitored for floating control or close control when the Direct Setting of
Position Proportional MV parameter is set to OFF.
Monitor/Setting Item Level
The contents displayed vary depending on the Monitor/Setting 1 to 5 (advanced function setting level) setting.
Advanced Function Setting Level
Transfer output
type
Setting (monitor) range Default (transfer output
upper/lower limits)
(See note 6.1.)
Unit
Set Point SP lower limit to SP upper limit SP upper limit/lower limit EU
Set Point During SP
Ramp
SP lower limit to SP upper limit SP upper limit/lower limit EU
PV Temperature input: Input set-
ting range lower limit to input
setting range upper limit
Input setting range upper/
lower limit
EU
Analog input: Scaling lower limit
to scaling upper limit
Scaling upper/lower limit EU
MV Monitor
(Heating)
Standard: −5.0 to 105.0
Heating/cooling: 0.0 to 105.0
100.0/0.0 %
MV Monitor
(Cooling)
0.0 to 105.0 100.0/0.0 %
Valve Opening −10.0 to 110.0 100.0/0.0 %
Parameters Characters Setting (monitor) value Display Default Unit Set value
Manual MV −5.0 to 105.0 (standard) (See
note 1.)
−105.0 to 105.0 (heating/cool-
ing) (See note 1.)
−0.5 to 105.0 (position propor-
tional) (See notes 1 and 2.)
0.0 %
Parameters Characters Setting (monitor) value Display Default Unit Set value
Parameter Initializa-
tion
init OFF, FACT off, fact OFF None
SP Ramp Time Unit
(See note 1.)
spru S: EU/second
M: EU/minute
H: EU/hour
s
m
h
MNone
Standby Sequence
Reset
rest Condition A, condition B a, b Condition A None
HB ON/OFF hbu OFF, ON off, on ON None
