326
Appendix
Auxiliary Output 1
Assignment
sub1 NONE: No assignment
O: Control output (heat-
ing)
C-O: Control output (cool-
ing)
ALM1: Alarm 1
ALM2: Alarm 2
ALM3: Alarm 3
P.END: Program end output
(See note 5.)
RALM: Control output ON/
OFF count alarm
WR1: Work bit 1 (See note 6.)
WR2: Work bit 2 (See note 6.)
WR3: Work bit 3 (See note 6.)
WR4: Work bit 4 (See note 6.)
WR5: Work bit 5 (See note 6.)
WR6: Work bit 6 (See note 6.)
WR7: Work bit 7 (See note 6.)
WR8: Work bit 8 (See note 6.)
none
o
c-o
alm1
alm2
alm3
p.end
ralm
wr1
wr2
wr3
wr4
wr5
wr6
wr7
wr8
ALM1 None
Auxiliary Output 2
Assignment
sub2 NONE: No assignment
O: Control output
(heating)
C-O: Control output
(cooling)
ALM1: Alarm 1
ALM2: Alarm 2
ALM3: Alarm 3
P.END: Program end output
(See note 5.)
RALM: Control output ON/
OFF count alarm
WR1: Work bit 1 (See note 6.)
WR2: Work bit 2 (See note 6.)
WR3: Work bit 3 (See note 6.)
WR4: Work bit 4 (See note 6.)
WR5: Work bit 5 (See note 6.)
WR6: Work bit 6 (See note 6.)
WR7: Work bit 7 (See note 6.)
WR8: Work bit 8 (See note 6.)
none
o
c-o
alm1
alm2
alm3
p.end
ralm
wr1
wr2
wr3
wr4
wr5
wr6
wr7
wr8
ALM2 None
Auxiliary Output 3
Assignment
sub3 NONE: No assignment
O: Control output
(heating)
C-O: Control output
(cooling)
ALM1: Alarm 1
ALM2: Alarm 2
ALM3: Alarm 3
P.END: Program end output
(See note 5.)
RALM: Control output ON/
OFF count alarm
WR1: Work bit 1 (See note 6.)
WR2: Work bit 2 (See note 6.)
WR3: Work bit 3 (See note 6.)
WR4: Work bit 4 (See note 6.)
WR5: Work bit 5 (See note 6.)
WR6: Work bit 6 (See note 6.)
WR7: Work bit 7 (See note 6.)
WR8: Work bit 8 (See note 6.)
none
o
c-o
alm1
alm2
alm3
p.end
ralm
wr1
wr2
wr3
wr4
wr5
wr6
wr7
wr8
ALM3 None
Character Select csel OFF, ON off, on ON None
Soak Time Unit t-u M: Minutes; H: Hours m, h MNone
Alarm SP Selection alsp SP-M: Ramp set point
SP: Set point
sp-m, sp SP-M None
Parameters Characters Setting (monitor) value Display Default Unit Set value
To Next Page
