Omron E5AN-H

36
Wiring Terminals Section 2-2
ALM1, 2, 3 can be output to auxiliary output 1, 2, 3 or changed with the
advanced function setting level.
• The relay specifications are as follows:
Event Inputs •The E5@N-H@@@B supports event inputs. When event inputs 1/2 are to
be used, connect to terminals 11 to 13, and when event inputs 3/4 are to
be used, connect to terminals 23 to 25.
• Use event inputs under the following conditions:
• The outflow current is approximately 7 mA.
Polarities during no-contact input are as follows:
E5@N-H (SUB1, SUB2) SPST-NO, 250 VAC, 3 A
E5@N-H (SUB3) SPDT, 250 VAC, 3 A
E5AN/EN-H
SUB1
SUB2
E5CN-H
SUB3
SUB2
SUB1
Contact inputON: 1 kΩ max., OFF: 100 kΩ min.
No-contact inputON: Residual voltage 1.5 V max.; OFF: Leakage current 0.1 mA
max.
E53-CN@B@N2
(for E5CN-H)
E53-AKB (for E5AN/EN-H)
11
12
13
23
24
25
EV1
EV2
EV1
EV2
EV1
EV2
E5AN-H/EN-H@B@M@-500
EV3
EV4
11
12
13
11
12
13
EV1
EV2
+
−
+
EV1
EV2
Two Event Inputs:
E53-CN@B@N2
(for E5CN-H)
+
−
+
EV3
EV4
23
24
25
11
12
13
11
12
13
+
−
+
Two Additional Event Inputs:
E53-AKB in E5AN/EN-
H@B@M@-500
(for E5AN/EN-H)
Two Event Inputs:
E5AN/EN-
H@B@M@-500
(for E5AN/EN-H)
