Setting the Input Type Section 3-2
• The default is 5.
• If a platinum resistance thermometer is mistakenly connected while a set-
ting for other than a platinum resistance thermometer is in effect, S.ERR
will be displayed. To clear the S.ERR display, check the wiring and then
turn the power OFF and back ON.
Platinum resistance
thermometer
Pt100 24 −50.0 to 200.0 (°C)/−50.0 to 200.0 (°F)
Current input 4 to 20 mA 25 Either of the following ranges, by scaling:
−19999 to 32400
−1999.9 to 3240.0
−199.99 to 324.00
−19.999 to 32.400
0 to 20 mA 26
Voltage input 1 to 5 V 27
0 to 5 V 28
0 to 10 V 29
Input type Specifications Set value Input temperature setting range
