• Do not apply stress to the connector by pulling or bending the cable. It may damage the connector.
•
Do not attempt to dismantle, repair, or modify the product.
• Should you notice any abnormalities, immediately stop use, turn OFF the power supply, and contact
your OMRON representative.
• While the power is ON or immediately after the power is turned OFF, the Sensor Controller and
camera case are still hot. Do not touch the case.
• When disposing of the product, treat it as an industrial waste.
• Do not drop the product nor apply excessive vibration or shock to the product. Doing so may cause
malfunction or burning.
• This product is heavy. Be careful not to drop it while handling.
• A lithium battery is incorporated, so a severe injury may rarely occur due to ignition or explosion.
• Be sure to take fail-safe measures externally when controlling stages and robots by using the meas-
urement results of the Sensor Controller (axis movement output by calibration and alignment meas-
urement).
Installation Environment (FH-SMDA-GS050B)
• Do not use the product in the environment with flammable or explosive gases.
•
To secure safety for operation and maintenance, install the product apart from high-voltage devices
and power devices.
• Avoid installing the product in places with vibration as much as possible.
Power Supply and Wiring (FH-SMDA-GS050B)
• Make sure to use the product with the power supply voltage specified. If a DC voltage exceeding the
rating or an AC voltage is applied, the circuit parts may be burnt or exploded.
•
Do not connect the power supply with polarity reversed.
• Use a DC power supply with safety measures against high-voltage spikes (safety extra low-voltage
circuits on the secondary side).
• Use an independent power source for this product. Do not use a shared power source.
• Never apply more than the rated voltage or AC power supply to this product. It may cause malfunc-
tion.
• The recommended power supplies are as follows:
- When not attaching the lighting module, use S8VK-G06024 (OMRON) or S8VS-06024 (OMRON).
• Wire high-voltage cables or power cables are separated from the cables of this product. If the same
cable or duct is used, the product may receive induction and it may cause malfunctioning or break-
age.
• Do not short-circuit the load on the open collector output.
• Apply load not exceeding the rating.
• Before wiring an I/O cable, attach a crimping terminal. Do not connect cables just twisted together to
the power supply or terminal block directly.
• Insulate unnecessary signal cables so that they do not contact any other signal cables.
• After wiring the cables, confirm if the power supply is appropriate, if there is miswiring such as short-
circuit of load, if the load current is appropriate, and if FG is connected appropriately. Otherwise, the
product may be broken due to miswiring etc.
• Take enough safety measures such as a failsafe circuit before using the product.
Precautions for Safe Use
18
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
