Omron fh series Hardware Setup Manual

1-1
Sensor Controller
First, please check to see whether the package has all the necessary Sensor Controller parts.
1-1-1
FH-5050
• Sensor Controller: 1
FH-5050: 1
•
Instruction sheet: 1
• Instruction Installation Manual for FH series: 1
• General Compliance Information and Instructions for EU: 1
• Membership registration: 1
• Power source: 1 (male)
FH-XCN: 1
• Ferrite core for camera cable: 2
1 Confirm the Package
1-2
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
