Basic System of Measurement
An FH series Sensor Controller uses pre-built packages that contain all the processing tasks (for im-
age input, measurement processing, displays, outputs, etc.) that are required for vision inspections.
You arrange these packaged processes in order of execution of the vision inspection.
An FH series Sensor Controller executes vision inspections according to user-created flows.
Additional Information
In the FH series Sensor Controller, a flow that contains packaged processes that are arranged
in order of execution of processing items and image processing is called a measurement flow.
Processing items and measurement flows can have more than one setting. You can switch the
setting based on the scene to inspect. (Refer to the Vision System FH series 3D Robot Vision
Application Construction Guide (Cat.No. Z446) and Vision System FH/FHV series User's
Manual (Cat.No. Z365).)
