3-2-3
Camera I/O Cable
Specification
• Camera I/O cable (straight)
Item FH-VSDX-BX 3M FH-VSDX-BX 5M FH-VSDX-BX 10M
Cable length 3 m 5 m 10 m
Cable type Bending resistance cable
Connector type Straight connector
Size AWG26
Outer diameter 5.8 mm dia.
Min. bending radius 35 mm
Usage environ-
ment
Ambient temper-
ature range
Operating: 0°C to +80°C, Storage: -20 to +80°C (with no icing or conden-
sation)
Ambient humidi-
ty range
Operating & Storage: 0 to 93% (With no condensation)
Ambient atmos-
phere
No corrosive gases
Vibration toler-
ance
Oscillation frequency: 10 to 150Hz, Half amplitude: 0.35 mm, Vibration di-
rection: X/Y/Z, Sweep time: 8 minutes/count, Sweep count: 10 times
Shock resist-
ance
Impact force: 150 m/s
2
, T
est direction: 6 directions, three time each (up/
down, front/behind, left/right)
Material Shell: Zinc alloy, brass, Sheath part: oil-resistant and heat-resistant poly-
vinyl chloride
Weight Approx. 220 g Approx. 320 g Approx. 570 g
• Camera I/O cable (right angle)
Item FH-VSDX-LBX 3M FH-VSDX-LBX 5M FH-VSDX-LBX 10M
Cable length 3 m 5 m 10 m
Cable type Bending resistance cable
Connector type Right angle connector
Size AWG26
Outer diameter 5.8 mm dia.
Min. bending radius 35 mm
Usage environ-
ment
Ambient temper-
ature range
Operating: 0°C to +80°C, Storage: -20 to +80°C (with no icing or conden-
sation)
Ambient humidi-
ty range
Operating & Storage: 0 to 93% (With no condensation)
Ambient atmos-
phere
No corrosive gases
Vibration toler-
ance
Oscillation frequency: 10 to 150Hz, Half amplitude: 0.35 mm, Vibration di-
rection: X/Y/Z, Sweep time: 8 minutes/count, Sweep count: 10 times
Shock resist-
ance
Impact force: 150 m/s
2
, T
est direction: 6 directions, three time each (up/
down, front/behind, left/right)
Material Shell: Zinc alloy, brass, Sheath part: oil-resistant and heat-resistant poly-
vinyl chloride
Weight Approx. 230 g Approx. 330 g Approx. 580 g
3 Configuration
3-15
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
3-2 Camera and Cables
3
3-2-3 Camera I/O Cable
