Dimensions
19.5 143
115
24 141
Four, M4 mounting holes
with a depth of 4.5 mm
19.2 143
182.5
24
141
190
20.1
Four, M4 mounting holes
with a depth of 4.5 mm
26.7 148.5
10.5 94
66.2
38.1
Four, M3 mounting holes
with a depth of 4.5 mm
Sensor Controllers
FH-series Box-type
FH-5050
(Unit: mm)
Additional Information
We have the 2D CAD data or 3D CAD data.
Y
ou can download CAD data from www.fa.omron.co.jp.
3 Configuration
3-8
FH Series Vision System Hardware Setup Manual for 3D Robot Vision (Z436-E1)
