Command Control
FQ2-S/CH User’s Manual
for Communications Settings
223
5
Appendices
103 Logging
control
Measurement
data
40: None
1: All
2: NG only
Specifies the logging con-
dition for measurement
data for each inspection
item.
104 Logging
control
Statistical data 4 0: None
1: Yes
Specifies whether or not to
record statistical data
(such as the number of
measurements, number of
NG judgments).
106 Parallel
control
OR output 4 0: OK: ON
1: NG: ON
Specifies the polarity when
the OUT0 output signal is
ON.
107 Parallel
control
Output delay 4 0 to 1,000 Specifies the ON delay
time (ms) from when the
measurement processing
completes until output
when using one-shot out-
put.
108 Parallel
control
Judgment out-
put mode
4 0: Level output
1: One-shot output
Specifies whether output is
one-shot output or level
output.
109 Parallel
control
One-shot out-
put time
4 1 to 1,000 Specifies the ON output
time (ms) when using one-
shot output.
110 Parallel
control
OUT0 polarity 4 0: Positive
1: Negative
Specifies the polarity for
the OUT0 output signal
(default assignment:
BUSY).
111 Parallel
control
OUT1 polarity 4 0: Positive
1: Negative
Specifies the polarity for
the OUT1 output signal
(default assignment: OR).
112 Parallel
control
OUT2 polarity 4 0: Positive
1: Negative
Specifies the polarity for
the OUT2 output signal
(default assignment:
ERROR).
113 Parallel
control
OUT0 signal
assignment
4 0: Control signal
1 to 32: OR0 to 31
1001 to 1032: Expression 1 to 32
2001: OR (overall judgement)
2002: BUSY
2003: ERROR
2004: READY
2005: RUN
2006: STG
Specifies whether to use
the signal as a control sig-
nal or to use the signal as a
judgment output (OR indi-
vidual output signal) for
inspection items.
System
data num-
ber
Ty p e Item Data
size
Range Description
FQ2-S_CH_comm.book 223 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
