Command Control
FQ2-S/CH User’s Manual
for Communications Settings
313
5
Appendices
*1 Depending on each inspection item type, the model registration region or measurement region is specified by the following values.
*2 Specify the setting value for the figure that is to be set as the model registration region or the measurement region in the following manner
for each figure type.
Inspection item types Command arguments
Region number Figure number
OCR 0 (measurement region) 0
Bar Code 0 (measurement region) 0
2D-code 0 (measurement region) 0
2D-code (DPM) 0 (measurement region) 0
Search 0 (model registration region) 0 to 7
1 (measurement region) 0
Shape Search II 0 (model registration region) 0 to 7
1 (measurement region) 0
Sensitive Search 0 (model registration region) 0 to 7
1 (measurement region) 0
Edge Position 0 (measurement region) 0
Edge Width 0 (measurement region) 0
Edge Pitch 0 (measurement region) 0
Color Data 0 (measurement region) 0 to 7
Area 0 (measurement region) 0 to 7
Labeling 0 (measurement region) 0 to 7
Figure type of specified
figure number
Response parameters
Parame-
ter 0
Parame-
ter 1
Parame-
ter 2
Parame-
ter 3
Parame-
ter 4
Parame-
ter 5
... Parame-
ter 20
Parame-
ter 21
Line with width Figure type
number
(4: Line
with width)
First X
coordinate
First Y
coordinate
Second
X coordi-
nate
Second
Y coordi-
nate
Line
width
... --- ---
Rectangle
Figure type
number
(8: Rectan-
gle)
Rectangle
upper-left
X coordi-
nate
Rectangle
upper-left
Y coordi-
nate
Rectangle
lower-right
X coordi-
nate
Rectangle
lower-right
Y coordi-
nate
--- --- ---
Oval
Figure type
number
(16: Oval)
Oval cen-
ter point X
coordinate
Oval cen-
ter point Y
coordinate
Oval X-
direction
radius
Oval Y-
direction
radius
--- --- ---
Circle with width
Figure type
number
(64: Circle
with width)
Circle cen-
ter point X
coordinate
Circle cen-
ter point Y
coordinate
Circle
radius
Width --- --- ---
Polygon
Figure type
number
(512: poly-
gon)
Number
of verti-
ces
Vertex 1
X coordi-
nate
Vertex 1
Y coordi-
nate
Vertex 2
X coordi-
nate
Vertex 2
Y coordi-
nate
Vertex
10 X
coordi-
nate
Vertex
10 Y
coordi-
nate
