Command Control
324
FQ2-S/CH User’s Manual
for Communications Settings
*1 These terminals status can only be set when the FQ2 execution mode is stop mode.
Terminal status
Specifies the ON/OFF status for the terminal. (ON: 1, OFF: 0) (0 to 16,383)
• Sensor's standard parallel communications
BIT1: ERROR
BIT2: BUSY
BIT3: OR
• Parallel Interface Sensor Data Unit
BIT0: RUN
BIT1: ERROR
BIT2: BUSY
BIT3: OR
*1
BIT5: GATE
*1
BIT9: STGOUT
*1
BIT11: SHTOUT
*1
BIT13: ACK
*1
• RS-232C Interface Sensor Data Unit
BIT0: RUN
BIT1: ERROR
BIT2: BUSY
BIT3: OR
*1
BIT9: STGOUT
*1
BIT11: SHTOUT
*1
BIT13: ACK
*1
For example, to turn ON OR
Specify 8.
FQ2-S_CH_comm.book 324 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
