Omron FQ2-S Series User Manual

Command Control
326
FQ2-S/CH User’s Manual
for Communications Settings
<Parameter Descriptions>
*1 These terminals status can only be set when the FQ2 execution mode is stop mode.
Terminal type Specifies the type of terminal for the terminal status to be set.
• Sensor's standard parallel communications
4: ERROR
5: BUSY
6: OR
• Parallel Interface Sensor Data Unit
3: RUN
4: ERROR
5: BUSY
6: OR
*1
7: GATE
*1
9: D0 to D15
*1
10: STGOUT
*1
11: SHTOUT
*1
12: ACK
*1
• RS-232C Interface Sensor Data Unit
3: RUN
4: ERROR
5: BUSY
6: OR
*1
10: STGOUT
*1
11: SHTOUT
*1
12: ACK
*1
Ter m i n a l nu m ber Specifies the terminal number for the terminal status to be set.
If the terminal type is D0 to D15
0: D0 to 15: D15
Cases other than the above cases
Specify 0
Terminal status • Specifies the ON/OFF status for the terminal.
0: OFF
1: ON
FQ2-S_CH_comm.book 326 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
