Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
349
5
Appendices
Load Commands for Binary Data Files
PRESCNLOADB (Check) / SCNLOADB (Execute)
Loading scene data (binary data)
The Sensor loads scene data in binary format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before loading scene data in binary data format, the Sensor checks whether or not it can receive binary data.
<Confirmation command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Execution command format>
Loads scene data in binary data format.
<Execution command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
PRESCN OADBL
C
R
File size scheduled to be sent
SC DB CR N LAO
Scene data number
Scene data
(binary)
Space
(0x20)
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
