Command Control
350
FQ2-S/CH User’s Manual
for Communications Settings
<Parameter Descriptions>
PRESGRLOADB (Check) / SGRLOADB (Execute)
Loading all scene data (binary data)
The Sensor loads all scene data in binary format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before loading all scene data in binary data format, the Sensor checks whether or not it can receive binary
data.
<Confirmation command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
File size scheduled to be sent Number of bytes of scene data scheduled to send (integer type)
Scene data number Specifies the scene number you want to load. (Integer type)
Specify 0 to 31.
Scene data (binary) Scene data to be loaded (binary data)
PR LOADB CR ES RG
File size scheduled to be sent
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
