<Execution command format>
Loads all scene data in binary data format.
<Execution command response format>
When the Command Is Processed Normally
When the Command Is Not Processed Normally
<Parameter Descriptions>
PRESYSLOADB (Check) / SYSLOADB (Execute)
Loading system data (binary data)
The Sensor loads system data in binary format.
To execute this command, two types of commands are used, a confirmation command and an execution
command.
For how to execute the command using the confirmation command and the execution command, refer to
Binary Data File Load and Save Commands: p. 183.
<Confirmation command format>
Before loading system data in binary data format, the Sensor checks whether or not it can receive binary data.
File size scheduled to be sent Number of bytes of all scene data scheduled to send (integer type)
All scene data (binary) All scene data to be loaded (binary data)
LOADB CR SGR
All scene data (binary)
Space
(0x20)
Delimiter
Delimiter
CR OK
CR ER
Delimiter
PR LOADB CR ES SY
File size scheduled to be sent
Space
(0x20)
Delimiter
FQ2-S_CH_comm.book 351 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
